Semantic Kernel to Microsoft Agent Framework: Practical reflections

At AgentCon 2025 Helsinki, I presented my multi-agent demo using Semantic Kernel orchestration.

On the same day, Microsoft announced Microsoft Agent Framework (MAF), so if I wanted to ever have the same presentation again I had to translate it to MAF instead. Now that it's nearing a GA release, I took my existing demo and translated it to see how the new framework feels in real code.

In this post I'll recap my thoughts on the new framework after taking it out for a spin.

The results can be found in these branches of the repo. I used version 1.0.0-rc1.

Let's get going!

Agent creation: less plumbing, more intent

In SK, my agent setup centers around Kernel composition and per-agent kernel wiring. In MAF, it is mostly chat client + instructions + tools.

Before (SK):

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/semanticKernel/Runtime/AgentUtils.cs#L26-L70
var builder = Kernel.CreateBuilder();
builder.Services.AddSingleton<IChatCompletionService>(chatService);
builder.Services.AddSingleton<IFunctionInvocationFilter, ConsoleFunctionInvocationFilter>();

var agentKernel = builder.Build();

return new ChatCompletionAgent
{
    Name = name,
    Instructions = instructions,
    Kernel = agentKernel,
    Arguments = args,
};

After (MAF):

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/feat/agentFramework/Runtime/AgentFactory.cs#L15-L24
return new ChatClientAgent(chatClient, new ChatClientAgentOptions
{
    Name = name,
    ChatOptions = new ChatOptions
    {
        Instructions = instructions,
        Temperature = temperature,
        Tools = tools ?? []
    }
});

This was the first thing I noticed: less ceremony, easier to read, easier to explain. I did like the previous kernel composition model, even though it was a bit more difficult to understand at first, but I'm sure this new model will grow on me as I get used to it.

Microsoft has these relevant docs in case you want to do the same migration:

Tool registration: plugin model -> plain function tools

In SK, you had to use plugin classes + [KernelFunction] and plugin import. Now in MAF, it's possible to just pass methods directly with AIFunctionFactory.Create(...).

Before (SK):

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/semanticKernel/Plugins/DevWorkflowPlugin.cs#L9-L30
public sealed class DevWorkflowPlugin
{
    [KernelFunction, Description("Generate OpenAPI from story and AC")]
    public string Oas_Generate(string story, string acceptance) => ...;
}

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/semanticKernel/Runners/SequentialRunner.cs#L22-L36
kernel.ImportPluginFromType<DevWorkflowPlugin>();

After (MAF):

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/feat/agentFramework/Runners/SequentialRunner.cs#L21-L28
var tools = new List<AITool>
{
    AIFunctionFactory.Create(DevWorkflowTools.OasGenerate),
    AIFunctionFactory.Create(DevWorkflowTools.RepoCreateBranch),
    AIFunctionFactory.Create(DevWorkflowTools.CreateScaffold),
};

This feels much more natural to me in C#: any function can become a tool without extra plugin lifecycle overhead.

Docs:

Workflow runtime model: orchestration runtime -> event stream

While SK gives the InvokeAsync(...) + GetValueAsync(...) style orchestration, MAF opts for a workflow event stream instead. With SK the result was always a bit different depending on the orchestration pattern, but with MAF I ended up with a more consistent pattern: we always return the list of assistant messages as the final output, and stream intermediate events during execution. I think this makes it easier to understand what is going on during execution, and gives more flexibility on how to handle intermediate events (e.g. tool calls) if needed.

Before (SK):

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/semanticKernel/Runners/ConcurrentRunner.cs#L89-L99
var orchestration = new ConcurrentOrchestration(diffAnalyst, testImpactor, secLint, compliance)
{
    ResponseCallback = AgentResponseCallbacks.Create(cli),
};

var runtime = new InProcessRuntime();
await runtime.StartAsync();

var result = await orchestration.InvokeAsync(prompt, runtime);
var output = await result.GetValueAsync(TimeSpan.FromSeconds(120));
await runtime.RunUntilIdleAsync();

After (MAF):

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/feat/agentFramework/Runtime/WorkflowRunner.cs#L35-L43
StreamingRun run = await InProcessExecution.RunStreamingAsync(workflow, messages, cancellationToken: cancellationToken);
await run.TrySendMessageAsync(new TurnToken(emitEvents: true));

await foreach (WorkflowEvent evt in run.WatchStreamAsync(cancellationToken))
{
    switch (evt)
    {
        case AgentResponseUpdateEvent e:
            // stream token and tool activity
            break;
        case WorkflowOutputEvent output:
            return output.As<List<ChatMessage>>() ?? [];
    }
}

One note here was that the AgentResponseUpdateEvent returns on each streamed token individually, so you might have to do some concatenation there.

Docs:

Filters vs middleware

SK uses filter interfaces. In my current MAF demo, I have not yet wired dedicated middleware in the main app - I currently intercept behavior in the workflow event loop. So basically the need for middleware for my use case here (plainly logging when tools are being called) was gone.

SK filter registration + filter implementation:

// Registration:
// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/semanticKernel/Program.cs#L59-L61
kernelBuilder.Services.AddSingleton<IFunctionInvocationFilter, ConsoleFunctionInvocationFilter>();

// Filter:
// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/semanticKernel/Runtime/ConsoleFunctionInvocationFilter.cs#L8-L31
public sealed class ConsoleFunctionInvocationFilter : IFunctionInvocationFilter
{
    public async Task OnFunctionInvocationAsync(FunctionInvocationContext context, Func<FunctionInvocationContext, Task> next)
    {
        var functionName = context.Function.Name;
        var pluginName = context.Function.PluginName;
        var caller = _id?.Name ?? "Agent";

        _cli.ToolStart(caller, pluginName ?? "", functionName);
        _log?.LogInformation("🔧 {Plugin}.{Func} by {Agent}", pluginName, functionName, caller);

        await next(context);
    }
}

MAF equivalent in this app: event-based interception in the workflow runner:

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/feat/agentFramework/Runtime/WorkflowRunner.cs#L38-L63
await foreach (WorkflowEvent evt in run.WatchStreamAsync(cancellationToken))
{
    switch (evt)
    {
        case AgentResponseUpdateEvent e:
            if (e.Update.Contents.OfType<FunctionCallContent>().FirstOrDefault() is { } call)
            {
                cli.ToolStart(
                    e.ExecutorId,
                    call.Name,
                    call.Arguments?.ToDictionary(x => x.Key, x => x.Value?.ToString() ?? "")
                    ?? new Dictionary<string, string>());
            }
            break;
    }
}

SK has explicit invocation filters in use, while MAF currently uses workflow event interception. MAF middleware APIs are available, and I will likely move this interception logic into middleware in a future iteration.

As an extra reference, here is a clean middleware example from Rasmus Wulff Jensen's samples repo:

AIAgent agentWithTools = client
    .GetChatClient("gpt-4.1")
    .AsAIAgent(
        instructions: "You are an expert a set of made up movies given to you (aka don't consider movies from your world-knowledge)",
        tools: [AIFunctionFactory.Create(searchTool.SearchVectorStore)]
    ).AsBuilder()
    .Use(FunctionCallMiddleware)
    .Build();

async ValueTask<object?> FunctionCallMiddleware(
    AIAgent callingAgent,
    FunctionInvocationContext context,
    Func<FunctionInvocationContext, CancellationToken, ValueTask<object?>> next,
    CancellationToken cancellationToken)
{
    StringBuilder functionCallDetails = new();
    functionCallDetails.Append($"- Tool Call: '{context.Function.Name}'");
    if (context.Arguments.Count > 0)
    {
        functionCallDetails.Append($" (Args: {string.Join(",", context.Arguments.Select(x => $"[{x.Key} = {x.Value}]"))}");
    }

    Utils.Gray(functionCallDetails.ToString());

    return await next(context, cancellationToken);

Docs:

Still a few rough edges in the prebuilt workflows

This was my biggest practical friction point in the rewrite. Handoff did not really work as expected with Human In The Loop (HITL) interactions in 1.0.0-rc1, and I had to implement a custom loop around the handoff workflow to get user input and feed it back into the workflow. Also, Magentic support was completely missing from the C# version of the package.

My SK handoff flow uses InteractiveCallback directly on orchestration. In my MAF demo (Microsoft.Agents.AI.Workflows 1.0.0-rc1), built-in handoff did not emit the RequestInfoEvent pattern I expected for a canonical HITL loop. Thus the callback never triggers like it does in the SK version, and I had to implement a custom loop around the workflow execution to feed user input back into the workflow. It's a bit rough and I probably would not use it in a production scenario, but it works for demo purposes.

Before (SK):

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/semanticKernel/Runners/HandoffRunner.cs#L50-L68
var orchestration = new HandoffOrchestration(...)
{
    InteractiveCallback = () =>
    {
        var input = responses.Count > 0 ? responses.Dequeue() : "No, bye";
        return ValueTask.FromResult(new ChatMessageContent(AuthorRole.User, input));
    }
};

After (MAF):

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/feat/agentFramework/Runners/HandoffRunner.cs#L48-L66
while (true)
{
    var workflow = CreateHandoffWorkflow(); // recreated each turn
    var turnResults = await WorkflowRunner.ExecuteAsync(workflow, messages, cli);

    foreach (var msg in turnResults.Where(m => m.Role == ChatRole.Assistant))
    {
        messages.Add(new ChatMessage(ChatRole.Assistant, msg.Text!) { AuthorName = msg.AuthorName });
    }

    if (!_simulatedResponses.TryDequeue(out var userResponse))
        break;

    messages.Add(new ChatMessage(ChatRole.User, userResponse));
}

Why this likely happens (at least in this RC shape):

AgentWorkflowBuilder.CreateHandoffBuilderWith(...) is built around tool-based handoff between agents.
RequestInfoEvent is tied to external request/response ports (RequestPort) and request flow handling.
The built-in handoff builder path does not automatically model that external request boundary in the same way, so no natural user-input request event showed up for my scenario.

In other words, HITL is absolutely possible in MAF workflows, but with handoff I would need a custom workflow that explicitly introduces request/response points where human input is required. That was out of scope for this demo app translation.

Docs:

Quick note on custom graph workflows

These feel powerful, and likely where many production use cases will end up.

I only did a first pass here, but even that looked promising:

// https://github.com/DrBushyTop/MultiAgentSemanticKernel/blob/feat/agentFramework/Runners/GraphRunner.cs#L251-L264
var builder = new WorkflowBuilder(startExecutor);
builder.AddFanOutEdge(startExecutor, [qualityReviewer, securityReviewer]);
builder.AddFanInBarrierEdge([qualityReviewer, securityReviewer], combinerExecutor);
builder.AddEdge(combinerExecutor, reportGenerator);
builder.WithOutputFrom(reportGenerator);

I will do a separate deep-dive post on graph workflows later as I gain more experience with using them in production applications. All in all, I still feel like the current LLM models are so powerful that it might not make much sense to make your code more complex with custom graph workflows unless you have a very specific need for it, but it's good to have the option there when you do.

I tend to think you'll get very far with building your Primary / Subagent flows like many coding agents do: Subagents exist to protect the context window of the Primary agent. More on that in my previous post here.

Final take

All in all, MAF left a positive impression on me. The API is arguably more straightforward and easier to use than SK was (I had no experience with AutoGen), and I think it will be more approachable for new users.

I do still think Microsoft needs to make a somewhat clear value proposition on when to use MAF vs other competitors in the space like LangGraph, but I can see MAF being a strong choice for teams that are already invested in the Microsoft ecosystem and want a first-party solution with good integration with Azure AI services and C#.
